GLOBE VALVE

Application

Throttling

​

Features / Benefit

OS & Y Construction
Welded & Renewable Seat Rings, Pressure Seal Welded Bonnet on request for High Pressure



Ansi Class / Rating

150#, 300#, 600#, 800#, 1500#, 2500#

Design Standard

BS 5352, API 602, ISO 15761, ASME B16.34

​

Testing Standard

API 598

Size

15 mm to 50 mm



Materials

Carbon Steel - A105, LF2
Alloy Steel - F5, F9, F11, F22, F91
Stainless Steel - F304L, F316
Duplex Steel - F51, F53, F55

​

Ends

Screwed End, Socket Weld End, Butt Weld End, Flange End

​

Operation

Manual
